SJYB-ⅢSC Type Class 100 Clean Side-Sealed Double-Head Fully Automatic Liquid Packaging Machine
Share
- Product Description
-
SJYB-ⅢSC Type Class 100 Cleanroom Side-Sealing Dual-Head Fully Automatic Liquid Packaging Machine
SJYB-ⅢSC Class 100 Cleanroom Grade Side-Sealing Dual-Head Fully Automatic Liquid Packaging Machine
Main Uses
This machine is designed and manufactured for packaging liquids and viscous materials that require a high level of cleanliness in the packaging environment. It is a Class 100 clean, side-sealing, high-speed, dual-head fully automatic packaging device.
Suitable for packaging the following products:
Pasteurized milk, dairy beverages, fermented yogurt and other dairy products; various sauces such as bean paste, jam, salad dressing; fruit juice, drinking water, plant protein beverages, cream, condensed milk, egg liquid, various soups, soy sauce, vinegar, cooking wine and other liquid seasonings and active biological bacteria.Technical Features
1. Equipped with a Class 100 clean laminar flow purification device on top, the entire machine completes the full packaging process under this purified environment;
2. Modular design, stainless steel components, transmission form combining servo motor and pneumatics;
3. Uses intelligent control systems such as PLC and human-machine interface touch screen;
4. Strong ultraviolet lamps sterilize the packaging film;
5. Supports CIP automatic circulation cleaning system;
6. Packaging material is PE film;
7. Fully automatic realization of bag making, filling, metering, sealing, cutting, date printing and other packaging processes;
8. The whole machine features high cleanliness, wide capacity adjustment range, fast operating speed, high metering accuracy, strong stability, long service life, convenient operation and flexible adjustment.Technical Performance Parameters
Production Capacity 90~134 bags/min; 50~90 bags/min Packaging Capacity 500~1000ml; 1000~500ml Film Width 240~350mm Metering Accuracy ±0.5~1% Working Pressure 0.65MPa Air Consumption 1.0m³/min (0.8Mpa) Power Supply Voltage C220V±10% 50Hz Maximum Power of the Whole Machine 4KW Overall Dimensions 1700(L)×1600(W)×3100(H)mm Total Weight 700Kg Product Video
Packaging Samples
Scope of Application
Cooperative Clients
Company Introduction
Harbin Said Technology Development Co., Ltd. was established in 1994, located in Harbin High-tech Industrial Development Zone. It was initiated and established by professors and experts from Harbin Institute of Technology, Harbin University of Commerce, China Aviation Industry Group Aerodynamics Research Institute, and other major institutions. It is a technology-based enterprise integrating "R&D, manufacturing, sales, and service."
The company has been deeply engaged in the field of fluid soft packaging machinery for more than 30 years, providing customers in various industries such as food, oils, agricultural supplies, daily chemicals, and chemicals with one-stop solutions for fully automatic soft packaging of liquids and viscous materials. It has developed more than ten varieties across five major series of fully automatic packaging machines, featuring reliable operation, simple operation, easy maintenance, high metering accuracy, energy saving and environmental protection, covering the full packaging range from 0.1L to 25L to meet the diverse needs of customers.
